ART Dualxdirect

Active Dual DI Box

• Can be operated via phantom power or 9V battery
• The incoming signal via the high-impedance, unbalanced jack and balanced XLR connectors is converted into an isolated, balanced and low-impedance signal
• Ground-lift switch
• Frequency response: 10 Hz – 100 kHz, ± 0.5 dB @ 0 dBu,
• Dynamic capture:> 100 dB (typical)
• Channel separation:> 80 dB (typical)
• Max. Input Level: 4, 34 dBu
• Max. Output level: 6 dBu (with battery operated), 14 dBu (powered by phantom power)
• Inputs: 1/4 “TRS
  XLR female balanced / unbalanced (2), 470k ohms
• Parallel bushing: 1/4 “TRS (2)
• Outputs: XLR male balanced. (2), <600 Ohm
• Input attenuation: Switchable, (0, -30 dB)
• Power supply: 9V @ 7.5mA (battery, alkaline), 18 – 48V DC @ 6.4mA (phantom power per channel)
• Dimensions (WxDxH): 99 x 117 x 47 mm
• Weight: 0.38 kg
