Drawmer 1968 MK II

2-Channel tube compressor

• BIG circuit implementable via sidechain
• Soft-knee compressors with variable threshold, attack, release, and output gain
• Stereo link or dual mono operable
• XLR in- and outputs
• VU meter with gain reduction
• VU normal and VU 10 dB
• Input impedance: 20k Ohms
• Maximum input level: +20 dBu
• Output impedance: 50 Ohms
• Maximum output level: +22 dBm (balanced)
• Frequency response: 17 Hz to 28 kHz -1 dB
• Signal to noise ratio: -85 dB
• Frequency range: 22 – 22,000 Hz
• Distortion: <0.35%
• Dimensions 19″/1U
