Meris 500 Series 440 Mic Preamp

Microphone Preamp in 500 Format

• Microphone preamp for recording guitar
• Up to 60 dB gain at the input section
• -27 dB to +12 dB Output Trim
• Post effect grinding path
• Selectable high-pass filter: 80 Hz / 200 Hz
• Selectable high-shelf filter: 7000 Hz / 4000 Hz
• Frequency response: 20 to 2000 Hz flat (all filters deactivated)
• 100% Analog signal path
• Controller for gain and output
• -20 dB Pad toggle switch for high-level input signals
• Phase toggle switch to reverse the signal phase
• +48 V toggle switch to enable phantom power
• High-shelf toggle switch to select the high-shelf filter frequency
• High-pass toggle switch to select the high-pass filter frequency
• Status LED for +48 V phantom power
• Metal housing
• 2 Front-side 6.3 mm mono-pin (send / return) connections
• Return socket can be used as DI input (post filters, pad and phase reversal)
• For mounting in racks of the 500 series
• Made in USANote: Register your product at www.w-distribution.com/Warranty and extend the warranty to 4 years.
